Second Hydraulic Circuit Installation for Signature Series Sprayers

Second Hydraulic Circuit Installation for Signature Series Sprayers

Recommended add-on for Signature Series sprayer builds where an additional hydraulic function is required.

This installation adds a second hydraulic circuit to support additional sprayer functionality and cleaner hydraulic control. It is intended for Signature Series sprayers that require a dedicated auxiliary hydraulic circuit with the proper valve, flow control, pressure release, hoses, couplers, and return-to-tank plumbing.

Included Components

• Diverter valve
• Flow control valve
• Pressure release
• Hydraulic hoses
• Hydraulic couplers
• Return-to-tank hydraulic plumbing
• Installation labour for integration into the sprayer hydraulic system

Why Add a Second Hydraulic Circuit?

• Provides a dedicated circuit for additional hydraulic functions
• Improves control of auxiliary hydraulic components
• Includes pressure release for safer hydraulic circuit service and operation
• Helps keep the sprayer hydraulic layout cleaner and easier to service
• Allows the sprayer to be set up for more advanced or customized operation
• Recommended when additional hydraulic control is needed beyond the standard sprayer setup

Best Suited For

• Signature Series sprayer builds
• Custom sprayer configurations
• Sprayers requiring an auxiliary hydraulic function
• Truck-mounted or skid-mounted liquid application systems

Note: Final configuration may vary depending on the truck, hydraulic supply, tank layout, controller setup, and selected sprayer options. Liquids Revolution will confirm compatibility and final layout during the build process.
